DESCRIPTION
The all-new Fathom II Lever Drag reels take a class-leading reel and raise the bar even more. New models, sizing, features, and optimized billfish models round out the assortment to give a model for every application. Integrating the palm side plate and frame allows the Fathom II Lever Drag reels to be more compact in hand and increases strength. The Pull-to-Turn preset knobs allow the angler to truly set it, and forget it. At the Fathom's core is a stainless steel main and pinion gear and a forged and machined aluminum spool for maximum durability.
FEATURES
- One-piece Machined Aluminum Frame and Sideplate for the Ultimate in Gear Strength
- Dura-Drag system
- Stainless Steel Main and Pinion Gear
- Pull-To-Turn Preset Knob Eliminates Accidental Changes to the Drag
- Forged and Machined Aluminum Spool
- Quick-Shift II 2-speed system
- 5 Stainless Steel Bearing System
- Removable Top Spacer Bar and Lugs (60 and 80 Sizes Only)
SPECIFICATIONS
#FTHII10XNLD2
Model: FTHII10XNLD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 6.2:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 32 Low: 14 |
| Weight | 15.8 oz |
| Braid Capacity (Lb Test/Yards) | Mono:8/350, 10/325, 12/220 Braid: 15/425, 20/345, 30/260 |
| Max Drag | 20 Lbs |
| Retrieve | Right |
#FTHII15LD2
Model: FTHII15LD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 6.2:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 32" Low: 14" |
| Weight | 16.6 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 10/515, 15/300, 20/200 Braid: 20/550, 30/410, 40/335 |
| Max Drag | 20 Lbs |
| Retrieve | Right |
#FTHII15XNLD2
Model: FTHII15XNLD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 18.7 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 10/670, 15/390, 20/260 Braid: 20/710, 30/535, 40/435 |
| Max Drag | 33 Lbs |
| Retrieve | Right |
#FTHII15XNLD2LH
Model: FTHII15XNLD2LH
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 18.7 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 10/670, 15/390, 20/260 Braid: 20/710, 30/535, 40/435 |
| Max Drag | 33 Lbs |
| Retrieve | Left |
#FTHII25NLD2
Model: FTHII25NLD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 20.1 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 20/330, 25/300, 30/245 Braid: 30/675, 40/555, 50/475 |
| Max Drag | 33 Lbs |
| Retrieve | Right |
#FTHII25NLD2LH
Model: FTHII25NLD2LH
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 20.1 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 20/330, 25/300, 30/245 Braid: 30/675, 40/555, 50/475 |
| Max Drag | 33 Lbs |
| Retrieve | Left |
#FTHII30LD2
Model: FTHII30LD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 20.3 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 25/405, 30/330, 40/255 Braid: 40/740, 50/635, 65/525 |
| Max Drag | 33 Lbs |
| Retrieve | Right |
#FTHII30LD2LH
Model: FTHII30LD2LH
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.5:1 Low: 2.8:1 |
| Line Per Handle Turn | High: 38" Low: 19" |
| Weight | 20.3 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 25/405, 30/330, 40/255 Braid: 40/740, 50/635, 65/525 |
| Max Drag | 33 Lbs |
| Retrieve | Left |
#FTHII40NLD2
Model: FTHII40NLD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 6.0:1 Low: 1.9:1 |
| Line Per Handle Turn | High: 50" Low: 16" |
| Weight | 24.1 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 30/410, 40/315, 50/235 Braid: 50/785, 65/655, 80/565 |
| Max Drag | 40 Lbs |
| Retrieve | Right |
#FTHII40NLD2LH
Model: FTHII40NLD2LH
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 6.0:1 Low: 1.9:1 |
| Line Per Handle Turn | High: 50" Low: 16" |
| Weight | 24.1 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 30/410, 40/315, 50/235 Braid: 50/785, 65/655, 80/565 |
| Max Drag | 40 Lbs |
| Retrieve | Left |
#FTHII60NLD2
Model: FTHII60NLD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 5.1:1 Low: 1.6:1 |
| Line Per Handle Turn | High: 50" Low: 16" |
| Weight | 32 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 50/340, 65/300, 80/215 Braid: 80/820, 100/700, 130/580 |
| Max Drag | 50 Lbs |
| Retrieve | Right |
#FTHII80LD2
Model: FTHII80LD2
| Bearings | 5 (4BB, 1RB) |
| Gear Ratio | High: 4.2:1 Low: 1.6 :1 |
| Line Per Handle Turn | High: 41" Low: 16" |
| Weight | 32.9 oz |
| Braid Capacity (Lb Test/Yards) | Mono: 60/420, 80/300, 100/260 Braid: 100/980, 130/815, 200/600 |
| Max Drag | 50 Lbs |
| Retrieve | Right |
